PDU socket strip vertical 36 x C13 12 x CEE7 3 6 phase
€561.58
Tax excluded
Aluminium profile width 44 mm, depth 47 mm, length ca. 1840 mm 36 x C13 and 12 x CEE7/3 2 x 3-phase feeding with phase labelling and colour marking (red/black/grey) Feeding 1: 18 x C13 + 6 x CEE7/3 (6 x C13 + 2 x CEE7/3 per phase) Feeding 2: 18 x C13 + 6 x CEE7/3 (6 x C13 + 2 x CEE7/3 per phase) 2 x Cable 3.0 m black, H05VV-F 5G 2.5 mm² with wire end sleeves Supplied mounting brackets allow any fastening position
Aluminium profile width 44 mm, depth 47 mm, length ca. 1840 mm 36 x C13 and 12 x CEE7/3 2 x 3-phase feeding with phase labelling and colour marking (red/black/grey) Feeding 1: 18 x C13 + 6 x CEE7/3 (6 x C13 + 2 x CEE7/3 per phase) Feeding 2: 18 x C13 + 6 x CEE7/3 (6 x C13 + 2 x CEE7/3 per phase) 2 x Cable 3.0 m black, H05VV-F 5G 2.5 mm² with wire end sleeves Supplied mounting brackets allow any fastening position
HP1037
Data sheet
- Phase
- 3
- Ampère
- 16
- Number of outlets
- 48
- Type outlets
- C13, CEE 7/3
- Type
- Basic
- Form
- 0U
- Cord length
- 3
- Mounting
- Vertical installation
Aluminium profile width 44 mm, depth 47 mm, length ca. 1840 mm 36 x C13 and 12 x CEE7/3 2 x 3-phase feeding with phase labelling and colour marking (red/black/grey) Feeding 1: 18 x C13 + 6 x CEE7/3 (6 x C13 + 2 x CEE7/3 per phase) Feeding 2: 18 x C13 + 6 x CEE7/3 (6 x C13 + 2 x CEE7/3 per phase) 2 x Cable 3.0 m black, H05VV-F 5G 2.5 mm² with wire end sleeves Supplied mounting brackets allow any fastening position
