PDU 1PH, 230V AC, 16A, 12 outlets 11x C13 1x C19, 3.7kVA Unit Metered and Switched, Zero U vertical

Monitored and switched rack power distribution unit (0U [vertical], 3.7kVA, 12 outlets).

INPUT: 230v, 16a - IEC 60309 2P+E 6h 16A plug (2P3W);

OUTPUT: 11x C13, 1x C19 outlets;

Billing-Grade (+/- 1%) Energy Metering [kW, kVA, V, A, Power Factor] - per inlet;

Remote Outlet Switching (Normally-Open Relays);

3-digit LED user-selectable display (voltage, current, or active power : per line).

Local display of alarms and configuration information(name, ratings, IP/Networking);

Onboard embedded processor with minimum 400MHz clock speed, 16MB NOR Flash, and 64MB SDRAM;

Remote network monitoring via HTML, JSON-RPC, SSH, Telnet, MODBUS/TCP, and SNMPv3.

Environmental monitoring [temp/humidity] capable ñ up to 32 sensors.

Individual outlet numbers labeled on chassis.

Automated deployment via TFTP, DHCP/PXE, SSH(CLI), or USB Flash Drives.

WiFi Capable.

USB Webcam Capable.

iPad/iPhone/Android App.

Max Dimensions 52mm x 65mm x 800mm (2.1in x 2.6in x 31.5in).

Max Weight 2.8 kg.

Maximum ambient temperature 50C at full load.
