PDU 1PH, 100-240V AC, 16A, 4 lines input type 4x IEC 60320 C20
PDU 1PH, 100-240V AC, 16A, 4 lines input type 4x IEC 60320 C20 PDU 1PH, 100-240V AC, 16A, 4 lines input type 4x IEC 60320 C20 PDU 1PH, 100-240V AC, 16A, 4 lines input type 4x IEC 60320 C20

PDU 1PH, 100-240V AC, 16A, 4 lines input type 4x IEC 60320 C20 output type 4x C19, 1U

€782.00
Tax excluded
1PH, 100-240V AC, 16A (16A rated), 4 lines, input type: 4x IEC 60320 C20, output type: 4x C19, 1U, high resolution color display, Ethernet, serial, 2x USB-A, USB-B and sensor connections
Quantity

Monitored rack power distribution unit (1U [horizontal], 0kVA, 4 outlets). INPUT: 230v, 16a - IEC 60320 C20 plug (2P3W); OUTPUT: 4x C19 outlets; FEATURES: Billing-Grade (+/- 1%) Energy Metering [kW, kVA, V, A, Power Factor] - per inlet; Color, matrix LCD display : Voltage, current, or active power (per line); Alarms; Configuration information (name, ratings, IP / Networking information). Auto-flip orientation.; 400MHz processor, 16MB NOR Flash, and 64MB SDRAM; (10/100) Ethernet portRemote network monitoring via HTML, JSON-RPC, SSH, Telnet, MODBUS/TCP, and SNMPv3. Environmental monitoring [temp/humidity] capable up to 32 sensors. Individual outlet numbers labeled on chassis. Automated deployment via TFTP, DHCP/PXE, SSH(CLI), or USB Flash Drives. WiFi Capable. USB Webcam Capable. iPad/iPhone/Android App. Max Dimensions 440mm x 183mm x 44mm (17.3in x 7.2in x 1.7in). Max Weight 4.1 kg. Maximum ambient temperature 60C at full load.
Raritan
PX3-3411

Data sheet

Phase
1
Ampère
16
Number of outlets
4 lines
Type outlets
C19
Inlet plug
IEC 60320 C20
Type
Line metered
Form
1U
Cord length
3
Dimensions
440mm x 183mm x 44mm
